Vestil EHLTTS-3654-2-48 LIFT & SIDE LINK TILT SCISSOR TABLE 2K

Vestil Item #EHLTTS-3654-2-48 · MFR #EHLTTS-3654-2-48
Quick Answer: The Vestil EHLTTS-3654-2-48 LIFT & SIDE LINK TILT SCISSOR TABLE 2K is a lift table with 2000 load capacity and 12 lowered height. Priced at $7,664.85, in stock with factory-direct shipping.
  • The Vestil EHLTTS-3654-2-48 performs both lifting and tilting operations.
  • There is a restraining chain and lip to keep the load in place during tilting.
Brand
Vestil
Condition
New
Weight
1127 lb
Dimensions
54″L × 38.25″W × 23.8125″H
🚚 Factory-Direct Shipping 🏷️ Volume Pricing Available 🛠️ Expert Support: (855) 719-1415 Sales & expertise backed by Premier Handling Solutions, Inc.

Product Details

The Lift & Tilt Scissor Lift performs both lifting and tilting operations. There is a restraining chain and lip to keep the load in place during tilting. Safety features include: electric toe guard to protect worker from pinch points during lowering of table, velocity fuses to hold platform position in an event of a hose or fitting failure, four (4) push-button hand pendant control, upper limit switch to stop travel at maximum height reducing motor wear, and maintenance prop. The end tilt is standard with a side tilt available. There is optional accordion skirting available for both the lifting and tilting portions of the table.

  • Lift & Tilt scissor lift includes a restraining chain and lip to keep load in place
  • Features an electric toe guard to protect workers during lowering
  • Velocity fuses hold platform position incase of a hose or fitting failure
  • Hand pendant control includes a switch to stop travel at maximum height

Specifications

Item NumberEHLTTS-3654-2-48
Manufacturer Part #EHLTTS-3654-2-48
Brand Vestil
Weight1127 lb
Dimensions (L×W×H)54″ × 38.25″ × 23.8125″
Lead Time60 days for 1–1 units · call for 2+ units
Load Capacity (lbs.)2000
Lowered Height (in.)12
Raised Height (in.)48
Platform Width (in.)36-1/4
Platform Length (in.)54
Deck Lip Height (in.)12
Coil Cord Length (in.)96
End Tilt (degrees)45
Power TypeElectric
Capacity (lbs)2000
MaterialSteel
ColorBlue
Freight Class70
Country of OriginUS
Warranty1 Year (Limited - Parts)

Documents & Resources

Approval Drawings

Testing Certificates

Warranty

Customer Reviews

No reviews yet — be the first to review this product.
